DS-L800F Fingerprint Smart Door Lock
Fingerprint / Mifare Card / Password / App (Bluetooth) / Remote Control / Mechanical Key
- DS-L800F fingerprint door lock with semiconductor fingerprint head, which is an intelligent and convenient door entrance solution.
- Unlock using your smart phone, change pin-codes and download unlocking records from the TTLock App.
- The lock body is made of Stainless Steel +Metal Panel which is smooth, beautiful, anti-rust and durable.
- The lock is powered with Long Lasting Batteries, up to 4 standard batteries can be installed, effectively powering the lock for 12 months. It doesn’t need any external power source.
- In case of low power, the mechanical keys can open the door and please replace a new battery.
- The lock suitable for inward and outward opening doors of a thickness between 38–55 mm.
Product Parameters
| Model No. | DS-L800F |
|---|---|
| Brand | Daosafe Security |
| Framework Material | Zinc alloy+304 stainless steel |
| Mortise | China standard anti-theft mortise |
| Identification Mode | Fingerprint, smart phone, mifare card, passcode |
| Fingerprint Capacity | 100 |
| Fingerprint Sensor | Semi-conductor (Silicon) |
| Password Capacity | 150(For custom), unlimited(For App send) |
| Card Capacity | 200 |
| Backup Power Interface | Micro-USB port supported |
| Card Module | M1(13.56 MHz) |
| Wireless Module BLE4.1 | BLE4.1 |
| Remote Access | Bluetooth gateway required |
| App Language | Multilingual support |
| Operating Temperature | -20°C - 70°C |
| Batteries | 4xAA alkaline battery (Not supplied) |
| Battery Life | Over 10000 times (Above 1 year) |
| Door Thickness | 38-55 mm |
| Front Panel Dimensions | Front panel - 77(W)×310(L)×20(D) mm |
| Back Panel Dimensions | Back panel - 77(W)×310(L)×30(D) mm |
| Packaging Weight | 3.6kg |
| Color Type | Silver/Antique Copper/Antique Brass/Black |
Easy Installing, No Need Any Special Electrician Skills
Replacement for Existing Ball Door Lock , Only for Single Latch.
